Na kaula uwea kila elevator maikai loa

ʻO ke kiʻi kiʻi kiʻi ʻia nā kaula uwea hao ʻeleʻele kiʻekiʻe

ʻO ka wehewehe pōkole:

Huahana Huahana

Nā Kūlana Huahana

1. He kūpono kēia kikoʻī no ke kaula uea limiter wikiwiki, haʻahaʻa haʻahaʻa, haʻahaʻa haʻahaʻa haʻahaʻa

2. Hiki iā mākou ke hana e like me kāu mau koi.

Anawaena kaula inoa	6*19S+PP	Haawe Ha'i li'ili'i
	Kaumaha pili	Kaulua, Mpa		Hookahi Tensile,Mpa
	Kaumaha pili	1370/1770	1570/1770	1570	1770
mm	Kg/100m	kN	kN	kN	kN
6	12.9	17.8	19.5	18.7	21
8	23	31.7	34.6	33.2	37.4

1.Natural fiber core (NFC): He kūpono no ke kaula uwea o ka mīkini traction me ka helu wikiwiki ≤ 2.0m / s

2.Ke kiʻekiʻe o ka hale≤80M

Anawaena kaula inoa	8*19S+NFC	Haawe Ha'i li'ili'i
	Kaumaha pili	Kaulua, Mpa		Hookahi Tensile,Mpa
	Kaumaha pili	1370/1770	1570/1770	1570	1770
mm	Kg/100m	kN	kN	kN	kN
8	21.8	28.1	30.8	29.4	33.2
9	27.5	35.6	38.9	37.3	42
10	34	44	48.1	46	51.9
11	41.1	53.2	58.1	55.7	62.8
12	49	63.3	69.2	66.2	74.7
13	57.5	74.3	81.2	77.7	87.6
14	66.6	86.1	94.2	90.2	102
15	76.5	98.9	108	104	117
16	87	113	123	118	133
18	110	142	156	149	168
19	123	159	173	166	187
20	136	176	192	184	207
22	165	213	233	223	251

1. No ka IWRC, ka wikiwiki> 4.0 m / s, ke kiʻekiʻe o ka hale> 100m

2.For IWRF, 2.0< speed≤4.0m / s, Building heigh≤100m

Anawaena kaula inoa	8*19S		Haawe Ha'i li'ili'i
	Kaumaha pili		Hookahi Tensile,Mpa
	Kaumaha pili		1570		1620		1770
	IWRC	IWRF	IWRC	IWRF	IWRC	IWRF	IWRC	IWRF
mm	Kg/100m		kN		kN		/	kN
8	26	25.9	35.8	35.2	36.9	35.2	40.3	39.6
9	33	32.8	45.3	44.5	46.7	45.9	51	50.2
10	40.7	40.5	55.9	55	57.7	56.7	63	62
11	49.2	49	67.6	66.5	69.8	68.6	76.2	75
12	58.6	58.3	80.5	79.1	83	81.6	90.7	89.2
13	68.8	68.4	94.5	92.9	97.5	98.5	106	105
14	79.8	79.4	110	108	113	111	124	121
15	91.6	91.1	126	124	130	128	142	139
16	104	104	143	141	148	145	161	159
18	132	131	181	178	187	184	204	201
19	147	146	202	198	208	205	227	224
20	163	162	224	220	231	227	252	248
22	197	196	271	266	279	274	305	300

ʻIkepili Huahana

ʻO nā elevators liʻiliʻi liʻiliʻi i hoʻohana ʻia no nā kaula uea elevator. Ma nā ʻāpana kūʻai hale kūʻai, ʻo nā kikoʻī o ke kaula uea eleeka ma ke ʻano he 8 * 19S + FC-8mm, 8 * 19S + FC-10mm. Hoʻohana nā hale kūʻai kūʻai i nā kikoʻī kikoʻī o ke kaula ʻeleʻele ʻoi aku ka nui o 12mm, 13mm, a me ka hoʻouka ʻana i nā kikoʻī kaula hao ʻeleʻele o 12mm, 13mm, a me 16mm ke anawaena.

I ke kauoha ʻana i ke kaula uea kila, ua noi ʻia ʻoe e hāʻawi iā mākou i ka ʻike piha e like me ka mea i ʻōlelo ʻia ma lalo nei:

1. Ke kumu: No ke kaula hea e hoʻohana ʻia ai;

2. Nui: Ke anawaena o ke kaula ma ka milimeter a i ole iniha;

3. Hana: Ka helu o nā kaula, ka helu o nā uea ma ke kaula a me ke ʻano o ke kūkulu ʻana;

4. Ke 'ano o ka Core: Fiber core (FC), kū'oko'a kaula kaula kumu (IWRC) a kūʻokoʻa uea strand core (IWSC);

5. Lay:Akau maʻamau moe, hema maʻamau moe, Right lang lay, hema lang lay,

6. Mea: Bright(ungalvanized), galvanized a staninless kila;

7. Papa o ka Uea: Tensile ikaika o na uea;

8. Lubrication: Inā makemake ʻia ka lubrication a i ʻole a makemake ʻia ka lubricant;

9. Length: lōʻihi o ke kaula uwea;

10. Hoʻopili: Ma nā ʻōwili i ʻōwili ʻia me ka pepa aila a me ka lole hessian a i ʻole ma nā pahu lāʻau;

11. Ka nui: Ma ka helu o nā wili a i ʻole nā mele ma ka lōʻihi a i ʻole ke kaumaha;

12. Manaʻo: Nā hōʻailona moku a me nā koi kūikawā ʻē aʻe.

I ka wā o ka hana lōʻihi, e emi mālie ka ʻaila lubricating ma ke kaula uea. No laila, pono e hoʻomaʻamaʻa mau ʻia ke kaula uea, hiki ke hoʻolōʻihi i ke ola lawelawe o ke kaula uea, a hoʻemi i ka ʻaʻahu a pale i ka ʻōpala ma ka relubricating. Ke hoʻohālikelike ʻia me kahi kaula wili lubricated piha, hiki ke hoʻemi ʻia ke ola lawelawe o kahi kaula uea maloʻo a hiki i 80%! He mea koʻikoʻi ka relubrication o ke kaula uwea. E koho maʻamau mākou i ka ʻaila lubricating T86, he wai lahilahi loa e hiki ke komo maʻalahi i loko o ke kaula uea. Pono ʻo ia i kahi pulupulu a i ʻole kahi pahu 1 lita paʻa e pulu ai. ʻO kahi o ka hoʻohana ʻana ma kahi o ke kaula uea e hoʻopā ai i ka puʻu traction a i ʻole ka huila alakaʻi, i hiki ai i ka lubricant kaula kaula ke kahe maʻalahi i ke kaula uea.
